Dimensions:
Height 12.7 mm (0.5 inch)
Depth 57.25 mm (2.25 inches)
Width 262.49 mm (10.33 inches)
Weight 214 g (.47 lb) for 4-cell version; 288 g (0.63 lb) for 6-cell
version
Voltage 14.8 for 4-cell version;11.10 VDC for 6-cell version
Capacity 23 WH for 4-cell version; 34 WH for 6-cell version
Charge time (approximate):
2
Computer on About 1.5 hours
Computer off About 1.5 hours
Life span (approximate)
2
350 discharge/charge cycles
Temperature range:
Charge 0° to 40°C (32° to 104°F)
Storage –20° to 50°C (–4° to 122°F)
AC Adapter
Input voltage 100 to 240 VAC
Input current (maximum) 1.5 A
Input frequency 50 to 60 Hz
Output current 2.64 A (maximum)
Rated output voltage 19.0 VDC
Height 29 mm (1.14 inches)
Width 46.3 mm (1.82 inches)
Depth 108 mm (4.25 inches)
Weight (with cables) 355 g (0.78 lb)
Temperature range:
