Modem Connector
You can connect a telephone line to the integrated modem through the RJ11 modem connector on the back of the
computer.
NOTICE: Do not confuse the modem and NIC connectors on your computer. Do not plug a telephone line into the
NIC connector.
NIC Connector
You can connect to the integrated network interface controller (NIC) through the RJ45 connector on the back of the
computer.
NOTICE: Do not confuse the modem and NIC connectors on your computer. Do not plug a telephone line into the
NIC connector.
External Media Options
You can connect external media options such CD-ROM, DVD-ROM, SuperDisk LS-120, and diskette drives to the external
media bay connector.
