Dell PRECISION MOBILE WORKSTATION M4600 - Page 8

Battery
NOTE: The Dell Precision M6600 Mobile Workstation only supports a 9–cell battery.
Depth 80 mm (3.14
inches)
Height 190 mm (7.48
inches)
Width 20 mm (0.78
inches)
Weight
365 g (0.80 lb) (6–cell)
500 g (1.10 lb) (9–cell / 9–cell LCL)
Voltage 11.10 V
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Non-operating –40 °C to 65 °C (–40 °F to 149 °F)
Coin-cell battery 3 V CR2032 lithium ion cell
AC Adapter M4600 M6600
Input voltage 100 VAC to 240 VAC 100 VAC to 240 VAC
Input current (maximum) 2.50 A 3.50 A
Input frequency 50 Hz to 60 Hz 50 Hz to 60 Hz
Output power 180 W 240 W
Output current 9.23 A 12.30 A
Rated output voltage 19.50 VDC 19.50 VDC
Dimensions: 180 W 240 W
Height 30 mm (1.18 inches) 25.40 mm (1 inch)
Width 155 mm (6.10 inches) 200 mm (7.87 inches)
Depth 76 mm (2.99 inches) 100 mm (3.93 inches)
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
8
