Dell Precision T3400 User Manual

About Your Computer 25
Front View (Desktop Orientation)
4 card slots Access connectors for any installed PCI or PCI Express
cards.
NOTE: The upper five connector slots support full-length
cards; the connector slot at the bottom supports a half-length
card.
NOTE: Check the documentation for cards to ensure that you
can accommodate them in your configuration. Some cards
that require more physical space and power (such as PCI
Express graphics cards) may restrict the use of other cards.
1 upper 5.25-inch drive
bay
Supports an optical drive.
2 lower 5.25-inch drive
bay
Supports an optical drive or an additional hard drive
(SATA only).
3 3.5-inch drive bay Supports a floppy drive or a Media Card Reader.
4 hard drive activity
light
The hard drive activity light is on when the computer
reads data from or writes data to the hard drive. The
light may also be on when a device such as an optical
drive is in operation.
1 2 7
8
9101112
3
4
5 6

Dell Precision T3400 Specifications

General

Processor Options	Intel Core 2 Duo, Intel Core 2 Quad
Chipset	Intel X38 Express
Memory	Up to 8GB DDR2 SDRAM
Storage Options	SATA hard drives
Graphics Options	NVIDIA Quadro FX 570, NVIDIA Quadro FX 1700, NVIDIA Quadro FX 3700, ATI FireGL V5600
Operating System	Windows Vista, Windows XP
Power Supply	525W
Expansion Slots	1 PCIe x16, 1 PCIe x1, 2 PCI
Ports	6 USB 2.0, 1 serial, 1 parallel, 1 PS/2
Optical Drive	DVD-ROM, DVD+/-RW
Weight	Approximately 40 lbs
