Mike Fortin – Avid Technology – June 24th, 2013
Rev E
E.) Nvidia Quadro GPU monitor connectivity:
The Nvidia Quadro 4000 graphics card has a single DVI port and two Display-Port ports
(Important: Display-ports
are not
HDMI ports; at first glance they do look very similar to HDMI ports)
( Please Note: Only two of the three video ports can simultaneously be used. Connecting to all three
video ports at the same time will result in non-functioning video output from the Nvidia GPU video
card.)
The Dell T5600 includes one Display-Port-to-DVI adapter. HP P/N 481409-002
For dual monitor connectivity:
1. Use the DVI port and one Display-Port (Display-Port connection can be native display-port to monitor via
display-port connection, or use the display-port-to-DVI-adapter supplied with the system to connect to a native
DVI monitor).
2. Or use two Display-Ports (Requires monitors with native display-port connections, two display-port to DVI
adapters are not recommended when using dual display-port connections).
