Dell T5600 - Page 4

Page 4 of 23
Mike Fortin – Avid Technology – June 24th, 2013
Rev E
AVID qualified HBA info
AVID qualified HBA
AVID Part Number
Slot
Location
Function
Vendor qualified 3
rd
party
hardware interface requiring:
x4 PCI-E or lesser interface
¾ Length PCI form factor or
smaller
Not stocked by AVID
#5
Vendor qualified 3
rd
party hardware interface. See
release notes and Avid website for information
regarding supported 3
rd
party hardware
Intel PRO 1000 PT
7030-20139-01
#4
Shared Storage: Unity ISIS Copper Gb-Ethernet
Dual Gb ISIS Connectivity
Intel i350-T2 – Dual Gb NIC
Not stocked by AVID
#4
Shared Storage: Unity ISIS Copper Gb-Ethernet
Dual Gb ISIS Connectivity
Intel PRO 1000 PF - ISIS
Not stocked by AVID
#4
Shared Storage: Unity ISIS Optical Gb-Ethernet
Myricom 10G-PCIE-8B-S
7030-30041-01
#4
Shared Storage: Unity ISIS 10Gb-Ethernet for
Hi-Res client (ISIS 5000 / 7000)
Avid HIB, DX Interface HBA **
Active: 7030-30048-01
Active: 7030-20084-01
Passive: 7030-30021-01
#5
Avid DX Hardware Interface HBA
Atto R680
Not stocked by AVID
#1
Local SAS Storage Support –
Avid VideoRAID ST (5-bay)
Xtore StudioRAID 5Ti (5-bay)
LSI 9200-8e SAS controller
7030-30036-01
#1
SAS Local Storage:
Xtore StudioRAID 16Re (16-bay) chassis
Xtore StudioRAID 5Te (5-bay) chassis
Pro Tools HD h/w
#4
Pro-Tools h/w for Pro-Tools co-install
Red Rocket Accelerator
Not stocked by AVID
#4
Accelerator for RED files
** Avid DX Interface HBA Support Note: (See reference pictures on page 7 of this guide).
All 3 versions of the DX interface HBA are supported on the T7600 with Media Composer / Symphony 6.x and
NewsCutter 10.x
1) Active DX interface HBA 7030-30048-01
2) Active DX interface HBA 7030-20084-01
3) Passive DX interface HBA 7030-30021-01
