U2412M/ U2412MWh
Displa y M ode
Hor iz onta l Fr equ e ncy
( k H z)
Vert ica l Frequency ( H z ) Pix el Clock ( MH z ) Sync Polarit y ( Hor izon t a l/ V e r tica l)
VESA, 720 x 400 31.5 70.0 28.3 - / +
VESA, 640 x 480 31.5 59.9 25.2 -/ -
VESA, 800 x 600 37.9 60.3 40.0 + / +
VESA, 1024 x 768 48.4 60.0 65.0 - / -
VESA, 1280 x 1024 64.0 60.0 108.0 + / +
VESA, 1600 x 1200 75.0 60.0 162.0 + / +
VESA, 1680 x 1050 64.7 59.9 119.0 + / -
VESA, 1920 x 1080 66.6 59.9 138.5 + / -
VESA, 1920 x 1200 74.0 60.0 154.0 + / -
Ele ct rica l Spe cificat ions
Model U2412M/ U2412MWh
Video input signals
Analog RGB, 0.7 Volt s + / - 5% , posit ive polar it y at 75 ohm input im pedance
Digit al DVI - D TMDS, 600m V for each different ial line, posit ive polar it y at 50 ohm
input im pedance
DP 1.1a signal input support
Synchronizat ion input signals
TTL levels required and separat e syncs ( including Trigger point s) , SOG ( Com posite
SYNC on green)
AC input
volt age/ frequency/ curr ent
100 t o 240 VAC / 50 or 60 Hz +
3 Hz / 1.2 A (t ypical)
I nrush current
120 V : 30 A ( Max)
240 V : 60 A ( Max)
Physica l Cha ract er ist ics
Model U2412M/ U2412MWh
Connect or t ype 15 - pin D- subm iniat ure, blue connect or; DVI - D, whit e connect or; DP, black connector .
Sign a l ca ble t ype
Digit al: det achable, DVI - D, solid pins, shipped det ached from t he m onit or
Analog: at t achable, D - Sub, 15pins, shipped det ached fr om t he m onitor
