Back Panel Connectors
Vostro 420
Vostro 220/220s
1 PS/2 mouse connector 2 VGA connector
3 USB 2.0 connectors (2) 4 link integrity light
5 network adapter connector 6 network-activity light
7 line-in connector 8 line-out connector
9 microphone connector 10 USB 2.0 connectors (4)
11 eSATA connector 12 serial connector (9-pin)
13 PS/2 keyboard connector
4562
7
8
13
12
13
9
11
10
45612
13 12 10
7
8
9
