28 Specifications
Audio
one front-panel microphone connector
one front-panel headphone connector
six rear-panel connectors for 7.1 support
System board connectors:
Serial ATA
six 7-pin connectors
Internal USB device
two 9-pin connector (supports four USB ports)
Floppy drive
one 34-pin connector
Processor fan
one 4-pin connector
Chassis fan
one 3-pin connector
PCI 2.3
three 124-pin connectors
PCI Express x1
two 36-pin connector
PCI Express x16
one 164-pin connector
Front panel control
one 9-pin connector
Front panel USB
two 9-pin connectors
Front panel audio HDA
header
one 9-pin connector
Processor
one 775-pin connector
Memory
four 240-pin connectors
Power 12V
one 4-pin connector
Power
one 24-pin connector
Connectors
