30 Specifications
Power
DC power supply:
Watt ag e
350 W
Maximum heat dissipation
(MHD)
188 W (350-W power supply)
NOTE: Heat dissipation is calculated by using the
power-supply wattage rating.
Voltage (See the safety
information that shipped
with your computer for
important voltage setting
information.)
115/230 VAC, 50/60 Hz, 8/4 A
Coin-cell battery 3-V CR2032 lithium coin cell
Physical
Height 36.2 cm (14.2 in)
Width 17.0 cm (6.7 in)
Depth 43.5 cm (17.1 in)
Weight 12.7 kg (28.0 lb)
Environmental
Temperature:
Operating
10° to 35°C (50° to 95°F)
Storage
–40° to 65°C (–40° to 149°F)
Relative humidity 20% to 80% (noncondensing)
Maximum vibration:
Operating
5–350 Hz at 0.0002 G
2
/Hz
Storage
5–500 Hz at 0.001–0.01 G
2
/Hz
Maximum shock:
Operating
40 G +/– 5% with pulse duration of 2 msec +/– 10%
(equivalent to 20 in/sec [51 cm/sec])
Storage
105 G +/– 5% with pulse duration of 2 msec +/– 10%
(equivalent to 50 in/sec [127 cm/sec])
book.book Page 30 Wednesday, March 5, 2008 9:45 PM
