24 Specifications
ExpressCard connector • 54-mm ExpressCard slot (supports both
USB- and PCIe-based interfaces)
Cards supported ExpressCard/54 (54 mm) (2.126 inches)
ExpressCard connector size 54 mm (2.126 inches)
8-in-1 Memory Card Reader
8-in-1 memory card controller O2MICRO OZ129
8-in-1 memory card connector 8-in-1 combo card connector
Cards supported
• Secure Digital (SD)
•SDIO
• MultiMediaCard (MMC)
•Memory Stick
• Memory Stick Pro
• xD-Picture Card
• Hi Speed-SD
• Hi Density-SD
Memory
Memory module connector 2 DIMM slots
Memory module capacity 512 MB, 1 GB, or 2 GB
Memory type DDR2 667 MHz
Minimum memory 512 MB
Maximum memory 4 GB
NOTE: In order to take advantage of the dual-channel bandwidth capability, both
memory slots must be populated.
NOTE: The available memory displayed does not reflect the complete maximum
memory installed because some memory is reserved for system files.
ExpressCard (continued)
