Specifications 31
Output current (65 W) 4.34 A (maximum at 4-second pulse)
3.34 A (continuous)
Output current (90 W) 5.62 A (maximum at 4-second pulse)
4.62 A (continuous)
NOTE: On a Vostro 1710 computer that has a discrete video configuration, you must
use the 90-W AC adapter that is shipped with your computer. Using the incorrect AC
adapter will prevent optimal system performance and produce a BIOS warning.
Rated output voltage 19.5 VDC (65 W and 90 W)
Dimensions (65 W):
Height
27.8–28.6 mm (1.10–1.12 inches)
Width
57.9 mm (2.28 inches)
Depth
137.2 mm (5.40 inches)
Dimensions (90 W):
Height
33.8–34.6 mm (1.34–1.36 inches)
Width
60.9 mm (2.39 inches)
Depth
153.4 mm (6.04 inches)
Weight (with cables)
0.46 kg (1.01 lb)
Temperature range 0° to 35°C (32° to 95°F)
Physical
Height Vostro 1310:
• 23.8–37.2 mm (0.937–1.465 inches)
Vostro 1510:
• 26.2–38 mm (1.031–1.496 inches)
Vostro 1710:
• 29–40.5 mm (1.142–1.594 inches)
AC Adapter (continued)
