Dell Vostro V13 - Internal Bluetooth Wireless Card Replacement; Removing the Bluetooth Card

Back to Contents Page
Internal Card With Bluetooth®Wireless Technology
Dell™Vostro™V13ServiceManual
Removing the Bluetooth Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the ExpressCard, if applicable.
3. Remove the SD card, if applicable.
4. Remove the base cover.
5. Remove the battery.
6. Remove the hard drive and audio board.
7. Remove the WLAN card.
8. Remove the LCD cover.
9. Remove the memory.
10. Remove the keyboard.
11. Remove the card reader.
12. Remove the coin-cell battery.
13. Remove the system board.
14. Remove the screw that secures the Bluetooth card to the system board.
15. Lift the Bluetooth card up and away from the system board.
Replacing the Bluetooth Card
To replace the Bluetooth card, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
