DeLonghi DEAPF40 - Before Plugging In; Service and Customer Care

Left
Parts Drawing
1. Front guard
2. Spinner
3. Fan blade
4. Rear guard nut
5. Rear guard
6. Screw for guards
7. Fan body
8. Stand xing screw
9. Stand post
10. Base xing screw
1234 65
7
8
9
10
Display panel
Remote control panel
Control panel
Normal
Low
Nature
Medium
Sleep
Fan speed
On/OffFan speed
Mode
Swing
Timer
Right
Oscillation angles
Mode
Swing
Timer
Oscillation
angles
RightLeft
On/Off
High
Swing
Timer
Display
