When positioning the appliance, always ensure that nothing obstructs the intake and discharge of
air
AIR CONDITIONING WITHOUT PERMANENT
INSTALLATION
Only a few simple steps are necessary to
obtain the comfort offered by Pinguino.
• Fit the air exhaust hose (14) in its housing (5)
at the rear of the appliance as shown in fig.1
• If you have a double window, use the
suckers (16) supplied to keep the panes from
opening wide (figure 3).
• Fit the window discharge attachment (15)
to the end of the hose (14)
• Place the air-conditioning unit at a win-
dow or French window
• Open the window a little and position the
attachment (15) as shown in fig. 2.
1
Setting up
2
3
