5
Preparing for use
en
ELECTRICAL CONNECTIONS
that:
indicated on the rating label on the back of the appliance;
appliance;
the case, you must choose another outlet.
Failure to follow these important safety instructions
absolves the manufacturer of all liability.
The power cable must be replaced by a qualied
professional only.
The instructions below will enable you to prepare your air
conditioner for operation as eciently as possible. Before
use, make sure the air intake and outlet grilles are
unobstructed.
AIR-CONDITIONING WITHOUT INSTALLATION
Just a few simple steps and your comfort is ensured with your
air conditioner:
13 to the hose’s end 12.
appliance. Insert it as shown in gure A.
17 to the other end of the
exhaust hose. (see g. B).
Sash window
15 in the window, extending it
to t the width of the window (g. C).
assembled exhaust hose 12 into the window bracket hole
15.
window aperture, use the additional window bracket
without holes extending it to the desired dimension,
then x the bracket by using the locking pin provided.
When extracting the window bracket and joining the two
pieces pay attention you do not cover the hole.
Other set-up methods:
bracket also for sliding windows. Position the hole of the
bracket so to allow a correct installation of the exhaust
hose (see gure D).
Keep the air hoses as short and free of curves as possible to
avoid constrictions.
A
