INTRODUCTION
ThankyouforchoosingaDe’Longhiproduct.Pleasetakeafew
momentstoreadtheinstructionstoavoidrisksordamagetothe
appliance.
DESCRIPTION
Description of the appliance (see page 3 - A)
A1 airoutletgrille
A2 controlpanel
A3 handles
A4 castorwheels
A5 BioSilverlter
A6 airintakegrille
A7 airexhausthosehousing
A8 airintakegrille
A9 powercable
A10drainagehosewith2caps
A11remotecontrolsignalreceiver
A12remotecontrolcompartment
Descrizione of the accessories (see page 3 - B)
B1 wallangewithcap
B2 airexhausthose
B3 hoseadaptor
B4 accessoryforwallmounting
B5 windowbracketwithpins
B6 additionalwindowbracket
B7 windowoutlet
B8 remotecontrol
B9 endofseasondustcover
B10endofseasonaccessoriesbag
Electrical connection
Beforepluggingtheapplianceintothetheelectricalreceptacle,
checkthat:
• Theoutlet’s powersupplycorrespondsto thevalue indi-
catedontheratinglabelonthebackoftheappliance;
• Theoutletandelectricalcircuitareadequatefortheappli-
ance;
• Theoutletisa3-holegroundedoutlet .Ifthisisnot
thecase,youmustchooseanotheroutlet.Failuretofollow
theseimportantsafetyinstructionsabsolvesthemanufac-
turerofallliability.
If it becomes necessary, the power cable must be re-
placed by a qualied professional only.
Theinstructionsbelowwillenableyoutoprepareyouraircon-
ditionerforoperationasecientlyaspossible.Beforeuse,make
suretheairintakeandoutletgrillesareunobstructed.
USE
AIR CONDITIONING WITHOUT INSTALLATION
For optimal results set-up in a double-hung window:
1) Placethebracket inthe window sill,extendthe bracket
fullywithinthewindowframe,xthebracketbyusingthe
pinthenlowerthewindowontothebracket,(shouldthe
windowbracketbetoolargeforthewindow.Theplastic
canbecutwithasawbyaqualiedprofessional.)
2) ScrewthehoseadaptorB3tothehose’sendB2.
3) Fittheairexhausthoseinthehousingatthebackofthe
appliance.Insertitasshowningure1.
4) ConnectthewindowoutletB7totheotherendoftheex-
hausthose.
5) Insertthewindowoutletendoftheexhausthoseintothe
slotofthewindowbracket(g.2).
Other set-up methods:
• Thankstothelockingpins,it’spossibletousethewindow
bracketalsoforslidingwindows.Positiontheholeofthe
bracketsotoallowacorrectinstallationoftheexhausthose
(seegure3).
