DeLonghi TCH8093ER Owner's Manual

6
the adjustment buttons + and – ( B ):
- Heating 1
The appliance operates at low power, reducing noise levels
and energy consumption to a minimum.
- Heating 2
The appliance operates at medium power.
- Heating 3
The appliance operates at high power to heat the room
rapidly.
Please note: Room temperature can be displayed in either °C or
°F. To change the unit of measurement for the temperature, press
the + button for approx. 10 seconds, then release.
5. “ECO plus” function
The “ECO plus” function is available in Heating 1, 2 and 3 modes
only. To activate the function, press the “ECO plus” button (D).
When this function is active the appliance automatically sets the
most appropriate power level to guarantee optimum comfort
while reducing energy consumption.
While the “ECO plus” function is active, the appliance may switch
automatically to a lower heating power than the one displayed.
This may happen a number of times in an hour.
6. Swivel button
To distribute the air ow over a wider surface, press the swivel
button (F) . The appliance swivels to the right and left.
To stop the appliance in the desired position, simply press the
swivel button (F) again.
7. Turn the appliance o
To turn the appliance o, press the ON/OFF button (A).
The display may show a countdown for about 6 seconds.
Digital 24 h timer (selection from 0.5 hrs to 24 hrs)
This function can be activated from any operating mode.
Auto-start: with the appliance in ON/OFF, press the timer
button (E) . The symbol is displayed together with the
time remaining before the appliance comes on.
To adjust the timer, use the adjustment buttons + and - (B), then
wait a few seconds for the setting to be stored. The stand-by light
(H) is displayed together with the symbol, indicating that the
timer has been set. When the programmed time is reached, the
appliance comes on with the settings used during the previous
period of operation.
Auto-o: Auto-o: with the appliance on, press the timer
button (E). The symbol is displayed together with the
time remaining before the appliance goes o. To set the timer,
use the adjustment buttons + and - (B), then wait a few seconds
for the setting to be stored. The current settings are displayed
again, together with the symbol indicating that the timer has
been set. When the programmed time is reached, the appliance
goes o automatically. To go back to operation without the timer,
press the timer button (E) twice.
The timer symbol disappears from the display.
Using the remote control
The functions on the remote control are the same as those on the
appliance control panel. For a description of the functions, see the
“Operation and use” section on the previous page.
Installing or replacing the batteries
The remote control is powered by
a CR2032 lithium battery.
To operate the remote control,
pull and remove the plastic strip
under the battery cover.
To replace the batteries, remove
the battery cover by sliding it
as shown in the gure. When
replacing the batteries, make
sure you respect the polarity (see
gure 2). Replace the cover as
shown in the gure. Old batteries
are harmful to the environment and must be removed
and disposed of in compliance with current legislation.
MAINTENANCE
- Always unplug from the outlet before cleaning.
- During the season when the appliance is in use, clean the air
intake and outlet grilles regularly using a vacuum cleaner.
- To clean the lter, remove the rear grille by pulling it
outwards (g. 1). Remove the dust lter that retains
impurities in the air drawn in from the room, blow on it
lightly then put it back in the appliance.
- Never use abrasive powders or solvents to clean the
appliance.
Safety functions
- Safety device: the appliance is tted with a safety
device that switches it o in the event of accidental
overheating (e.g. obstruction of air intake and outlet
grilles, motor turning slowly or not at all). To reset,
unplug the appliance from the outlet for a few minutes,
remove the cause of overheating, then plug in again.
- Tip-over safety device: a tip-over safety device
turns the appliance o if it falls over or is positioned
inappropriately in such a way as to jeopardize safety.
The appliance emits a beep and a dot ashes on the
display. The appliance resumes operation a few seconds
after being placed in an upright position again.
en
Maintenance/Safety functions
Fig. 2
For service questions, contact DeLonghi at 1-800-322-3848.
For sales inquiries, call Sylvane at 1-800-934-9194.

DeLonghi TCH8093ER Specifications

General

Type	-
Heating power	2400 W
Heating power (min)	800 W
Adjustable thermostat	Yes
Suitable for room volume up to	70 m³
Product color	Black, White
Placement options	Floor
Heat source	Electric
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	269 mm
Width	275 mm
Height	695 mm
