BURNER FLAME PATTERN
Figure 15 shows a correct burner flame pat-
tern. Figure 16 shows a incorrect burner flame
pattern.
If burner flame pattern is incorrect, as shown
in figure 16
• turn heater off (see to turn off gas to appli-
ance, page 12)
• see troubleshooting, pages 16 through 18
13
correct burner
fig. 16
fig. 15
incorrect burner
