Warning:
Observe refrigerant handling
precautions (refer to N:04:01).
13.
ENSURE THAT THE SYSTEM IS FULLY
DEPRESSURIZED BEFORE CARRYING OUT
FURTHER WORK.
14.
Release both evaporator pipe connections,
using two spanners and cap the four connector
ends immediately, releasing the accumulator
mounting bracket from the body if necessary.
15.
From inside re-circulation vent aperture,
release screws securing fan housing to body.
16.
Remove bracket securing heater/air condition-
ing unit to tunnel top.
17.
Withdraw footwell duct from under heater/air
conditioning unit.
18.
Disconnect plain black vacuum supply pipe
from port 1 of the selector switch
plug,
and
disconnect the black and orange water
valve/recirculator
pipe from port 3.
19.
Withdraw heater/air conditioning unit.
