DELTA DORE TYDOM 1.0 Installation Instructions

32 33
EN
1/ INSTALLATION
Replace the light switch with the TYXIA 6610
❶ Check that the installa on is switched o .
❷ Remove the cable glands.
❸ Fit a H03VVH2-F 2*0,75 mm² cable.
Strip the wires using the strip gauge.
❹ Insert the wires in the cable glands.
Ensure the wires are correctly posi oned.
❺ Fit the wires for the light
and the mains supply.
❻ Place the wires in the cable ducts.
Insert the cable glands into their housing.
❼ Close the receiver unit and  ghten the four screws.
❽ Fit the non-slip pads,
Reconnect the power supply.
2
1
230V~
OFF
3
9 mm
20 mm Max.
H03VVH2-F
4
1
5
2
L N
7
2
1
6
8
230V~
ON
