Delta Electronics AE57BSTD - Page 11

English-10
MODEL AS38BSTD(-W) AS57BSTD A(E)57BSTD(-W) A(E)57GSTD(-W)
Ambient Humidity
10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Pollution Degree 2
Vibration
Resistance
IEC 61131-2 Compliant
5Hz≦f＜9Hz = Continuous: 1.75mm / Occasional: 3.5mm
9Hz≦f≦150Hz = Continuous: 0.5g / Occasional: 1.0g
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
140.8 x 104.8 x
44.8
184.1 x 144.1 x 47
Panel Cutout
(W) x (H) mm
118.8 x 92.8 172.4 x 132.4
Weight Approx. 310g Approx. 760g
NOTE
1) DOP-AE94BSTD this model is not UL recognized.
2) Users please use isolated power supply except DOP-A80THTD1, DOP-AE80THTD, DOP-AE94BSTD, and
DOP-A(E)10THTD1 these models.
3) Users can download the Screen Editor, the program editor of Delta HMI product and the user manual via the
following link: http://www.delta.com.tw/industrialautomation/.
4) The content of this quick start may be revised without prior notice. Please consult our distributors or download the
most updated version at http://www.delta.com.tw/industrialautomation/.
