English-11
MODEL A(E)57CSTD(-W)
A80THTD1
AE80THTD
AE94BSTD A(E)10THTD1
Display Type
5.7” STN LCD
(256 colors)
8” TFT LCD
(65536 colors)
9.4” STN LCD
(8 shades of blue)
10.4” TFT LCD
(65536 colors)
Resolution 320 x 240 pixels 640 x 480 pixels
Back Light
CCFL Back Light
(about 50 thousand
hours at 25
o
C)
CCFL Back Light
(about 50 thousand
hours at 25
o
C)
CCFL Back Light
(about 30 thousand
hours at 25
o
C
CCFL Back Light
(about 30 thousand
hours at 25
o
C
LCD MODULE
Display Size
5.7” (115.17 x
86.37mm)
8” (162.2 x
121.7mm)
9.4” (192.0 x
144.0mm)
10.4” (211.2 x
158.4mm)
Operation System
Windows Base Real Time OS
MCU
32-bit RISC Micro-controller
NOR Flash ROM
NOR Flash ROM 4
Mbytes (System:
1MB / User: 3MB)
NOR Flash ROM 8 Mbytes (System: 1MB / User: 7MB)
SDRAM
16 Mbytes 32 Mbytes 16Mbytes 32 Mbytes
Backup Memory
(Bytes)
A: 256K
AE: 512K
512K 512K 512K
SM Card
3
3 (AE)
EXT.
Memory
USB Host
(Ver 1.1)
3 3 3
Extension Interface
3 (AE)
3 (AE)
3
3 (AE)
USB for Download
[USB Client]
1 USB Client Ver 1.1
USB for Data
Storage / Printer
[USB Host]
3 3 3
COM1
RS-232
COM2
RS-232 / RS-422 / RS-485
Serial
COM
Port
COM3
RS-232 / RS-422 /
RS-485 (AE)
RS-232 / RS-422 / RS-485
Function Key
User defined key x
4 + System key x 1
User defined key x
6 + System key x 1
User defined key x
11 + System key x
1
User defined key x
7 + System key x 1
Operation Voltage
DC +24V (-10% ~ +15%) (Please use isolated power supply)
(Note 2)
Backup Battery
3V lithium battery CR2032 x 1 / battery life: 5 years
Buzzer 85dB
Perpetual Calendar
(RTC)
Built-in
Cooling Method Natural air circulation
Safety Approval
(Waterproof for
front panel)
IP65 / NEMA4 / CE, UL
(Note 1)
Operation Temp.
0°C ~ 50°C
