CTA USER MANUAL
© DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED - 21 - 2007-05-09
At this time, the sensor detects the speed and sends it back to tachometer. Assume the value displayed on
the screen is 3,200rpm,
F × 60/3 = 3,200
F = 160Hz
Figure 1 Figure 2
