Delta 6902 User Manual




8
SECTION 1: CRIB ASSEMBLY
STEP 3
PARTS AND TOOLS REQUIRED TO COMPLETE STEP
J. BOLT - 66mm x 2
L. BARREL NUT x 2
M. METAL DOWEL x 2
M4 ALLEN WRENCH
SUPPLIED
F. STABILIZER BAR


ATTACH THE STABILIZER BAR (PART F) TO THE LEFT AND
RIGHT CRIB ENDS USING (1) METAL DOWEL (PART M), (1)
BOLT-66mm (PART J) AND (1) BARREL NUT (PART L) AT
EACH END. BE CAREFUL TO SPREAD THE CRIB SIDE
POSTS OUT BEFORE INSERTING THE STABILIZER BAR.
SPREAD ONLY AS MUCH AS IS NECESSARY
USE THE SCREWDRIVER TO HOLD THE BARRELNUT IN
THE PROPER ALIGNMENT.
DO NOT TIGHTEN AT THIS
TIME
FROM STEP 2
F
L
M
J
BOTH ENDS
FLAT HEAD SCREWDRIVER
REQUIRED FOR ASSEMBLY
- NOT INCLUDED
