6
P. M6x15mm Bolt x4
T. Mattress Support
SECTION 1: CRIB ASSEMBLY
STEP 2
PARTS AND TOOLS REQUIRED TO COMPLETE STEP
Attach the Mattress Support (Part T) in all corners using (1) M6x15mm Bolt (Part P) in each corner.
Do not tighten any of the bolts until all have been started. Use the M4 Allen Wrench to tighten the
bolts.
The WARNINGS printed on the pouch attached to the mattress support must
face up, the springs must face up.
This crib has (3) adjustment positions, use the highest only for newborns, move the mattress down
as the child grows.
Fall Hazard: When child is able to pull to a standing position or
reaches a height of 35in (90cm) whichever occurs first, set
mattress to lowest position and remove bumper pads, large toys
and other objects that could serve as steps for climbing out.
WARNING
P
UP
WARNINGS MUST FACE UP
EACH CORNER
T
From Step 1
To Next Page
