Delta AS00SCM-A User Manual

Chapter 5 Analog Input/Output Module AS06XA
5- 5
5_
 Functional specifications for the digital-to-analog conversion
Digital-to-Analog
Conversion
Voltage Output
Rated Output Range ±10 V
0 ~ 10 V
±5 V
0 ~ 5 V 1 ~ 5 V
Conversion Range
K-32000
~
K32000
K0
~
K32000
K-32000
~
K32000
K0
~
K32000
K0
~
K32000
Hardware Output Range
-10.1 V
~
+10.1 V
-0.1 V
~
10.1 V
-5.05 V
~
+5.05 V
-0.05 V
~
+5.05 V
0.95
~
5.05 V
Error Rate
(Room Temperature)
±0.2%
Error Range
(Full temperature range)
±0.5%
Linearity Error
(Room Temperature)
±0.05%
Linearity Error
(Full Temperature Range)
±0.05%
Hardware Resolution 12 bits
Permissible load
impedance
≧1kΩ ≧500Ω
Digital-to-Analog
Conversion
Current Output
Rated Output Range 0–20 mA 4–20 mA
Conversion Range
K0
~
K32000
K0
~
K32000
Hardware Output Range -0.2 mA to 20.2 mA 3.8–20.2 mA
Error Range
(Room Temperature)
±0.2%
Error Range
(Full Temperature Range)
±0.5%
Linearity Error
(Room Temperature)
±0.03%
Linearity Error ±0.10%
