Chapter 5 Analog Input/Output Module AS06XA
5- 11
5_
CR# Name Description
Atr. Defaults
45
The maximum scale range
for input channel 1
If the scale range for an analog to digital input
channel is 4 mA ~ 20 mA. It indicates the
maximum value is 20 mA and the minimum
value is 4 mA.
Note: You can use PLC instruction DSCLP
(API0217
) and set SM685 to ON to use
floating-point operations when a conversion
range needs to edit.
10.0
46
47
The maximum scale range
for input channel 2
10.0
48
49
The maximum scale range
for input channel 3
10.0
50
51
The maximum scale range
for input channel 4
10.0
52
53
The maximum scale range
for output channel 1
10.0
54
55
The maximum scale range
for output channel 2
10.0
56
201
Instruction Set
Instructions for peak values
16#0101: record the peak value again for
channel 1
16#0102: record the peak value again for
channel 2
16#0104: record the peak value again for
channel 3
16#0108: record the peak value again for
channel 4
16#010F: record the peak values again for
channels 1–4
16#0201: enable recording for channel 1
16#0202: enable recording for channel 2
16#0204: enable recording for channel 3
16#0208: enable recording for channel 4
16#020F: enable recording for channels 1–4
16#0211: disable recording for channel 1
16#0212: disable recording for channel 2
16#0214: disable recording for channel 3
16#0218: disable recording for channel 4
16#021F: disable recording for channels 1–4
16#0502: restore default settings
W 0
