Delta AS00SCM-A User Manual

AS Series Module Manual
8- 10
_8
CR#200: Codes for the state register
Explanation
Bit Code Definition Bit Code Definition
b0 16#0001 Error exists in the power supply. b1 16#0002 Error exists in the module hardware.
b2 16#0004 Error exists in the driver board. b3 16#0008 Calibration disabled
b4 16#0010 Reserved b5 16#0020 Reserved
b6 16#0040
The weight measured by CH1
exceeds the maximum weight that
can be measured, or the voltage of
SEN is incorrect.
b7 16#0080
The weight measured by CH2
exceeds the maximum weight that
can be measured, or the voltage of
SEN is incorrect.
b8 16#0100
The weight measured by CH1
exceeds the maximum weight that
can be measured.
b9 16#0200
The weight measured by CH2
exceeds the maximum weight that
can be measured.
b10 16#0400 CH1 has been adjusted incorrectly. b11 16#0800 CH2 has been adjusted incorrectly.
b12 16#1000 CH1 is not measuring any weight. b13 16#2000 CH2 is not measuring any weight.
b14 16#4000
The weight measured by CH1 is in
the stability range specified.
b15 16#8000
The weight measured by CH2 is in
the stability range specified.
Note: The state is determined by the corresponding bit and it is possible to have more than 2 states at the
same time.
CR#201: Command set
Explanation
Input
value
Description Input value Description
0 No action 16#0101
Start a new recording of the peak value
for CH1.
1–20
Commands for calibrating the calibration
points 1–20 on CH1
16#0102
Start a new recording of the peak value
for CH2.
21–40
Commands for calibrating the calibration
points 1–20 on CH2
16#010F
Start a new recording of the peak value
for CH1 - CH2.
98 Activate the weight calibration. 16#0201 Start a new recording for CH1.
99 Deactivate the weight calibration. 16#0202 Start a new recording for CH2.
