Delta AS00SCM-A User Manual

AS Series Module Manual
10-10
10
SM Function
AS300 Series AS200 Series
OFF

ON
STOP

RUN
RUN

STOP
Latched
Attribute
Default
SM1030
Error in data exchange connection 7 through AS-
FEN02
○ – OFF – – N R OFF
SM1031
Error in data exchange connection 8 through AS-
FEN02
○ – OFF – – N R OFF
Special auxiliary
relay
Refresh time
SM1006
After the parameters of data exchange are downloaded, you set the flag to ON or OFF.
SM1008~SM1015
After the parameters of data exchange are downloaded, you set the flag to ON or OFF.
SM1016~SM1031
The flag is ON, when the system is refreshed automatically.
 Special Data Registers (SR)
SR Function
AS300
Series
AS200
Series
OFF

ON
STOP

RUN
RUN

STOP
Latched
Attribute
Default
SR1520
Actual connection time for data exchange through the
AS-FEN02 connection 1
○ – 0 – – N R 0
SR1521
Actual connection time for data exchange through the
AS-FEN02 connection 2
○ – 0 – – N R 0
SR1522
Actual connection time for data exchange through the
AS-FEN02 connection 3
○ – 0 – – N R 0
SR1523
Actual connection time for data exchange through the
AS-FEN02 connection 4
○ – 0 – – N R 0
SR1524
Actual connection time for data exchange through the
AS-FEN02 connection 5
○ – 0 – – N R 0
SR1525
Actual connection time for data exchange through the
AS-FEN02 connection 6
○ – 0 – – N R 0
SR1526
Actual connection time for data exchange through the
AS-FEN02 connection 7
○ – 0 – – N R 0
SR1527
Actual connection time for data exchange through the
AS-FEN02 connection 8
○ – 0 – – N R 0
SR1528
The error code for data exchange through the AS-
FEN02 connection 1
○ – 0 – – N R 0
SR1529
The error code for data exchange through the AS-
FEN02 connection 2
○ – 0 – – N R 0
SR1530
The error code for data exchange through the AS-
FEN02 connection 3
○ – 0 – – N R 0
SR1531
The error code for data exchange through the AS-
FEN02 connection 4
○ – 0 – – N R 0
SR1532
The error code for data exchange through the AS-
FEN02 connection 5
○ – 0 – – N R 0
SR1533
The error code for data exchange through the AS-
FEN02 connection 6
○ – 0 – – N R 0
SR1534
The error code for data exchange through the AS-
FEN02 connection 7
○ – 0 – – N R 0
