AS Series Module Manual
10-22
10
g. Save Configuration: After any setting is done, save the settings in Save Configuration to reflect the changes.
 When AS-FEN02 is installed on AS00SCM-A
a. Use the switches on AS00SCM-A to set the AS-FEN02 IP address. Open your browser and enter AS-FEN02
IP address in the search bar to connect to AS-FEN02. After the webpage appears, enter “Admin” in the User
section and click Login without entering any password. You can set up the password after login.
b. The menu shows data based on the permission of the current user. When it is installed on AS00SCM-A, you
can monitor the Hardware Status.
Nodes
Permission
Administrator Read
Device information V V
Account management V X
Firmware update V X
Hardware status V V
DLR status V V
Save configuration V X
c. Hardware Status: you can monitor the connected right-side I/O modules, including their module names, the
current values, statuses and error codes. You can edit the values in the Refresh Cycle to update the cycle.
