23- ENG
D25886
PARTS LIST
Key No Part Number Description
1 D25734 Shroud, Left
2 AC-0470 Shroud, Right
3 CAC-1196 Cylinder Head
4 * CAC-1212 Tube Seal
5 * CAC-1199 Gasket Head
6 Z-D24985 Valve Plate Assembly
7 DAC-269 Outlet Tube
8 * SSG-8169 O-ring
9 + ————— Rod Assembly
10 CAC-1206-1 Clamp
11 AC-0206 Isolator Tube
12 x SSF-3147 Screw 3/8-16 x .375
13 + ————— Cylinder Sleeve
14 ————— Endbell Assembly
15 x SUDL-9-1 Screw 8-32x .375/.344
16 AC-0815 Timing Belt
18 x SSF-3156 Screw, 10-9x.50 Plastite (5 used)
20 * D24731 Pump Isolator (5 used)
21 x SSF-995 Screw #10-24 x .875 (4 used)
Not Shown
D20111 Motor Cord
Kits A
vailable
* K-0387 Isolator Kit
+ KK-4964 Connecting Rod Kit
x KK-4929 Fastener Kit
