MODEL AS35THTD AS38BSTD AS57B(C)STD A(E)57BSTD A(E)57GSTD
Storage Temp.
-20°C ~ +60°C
Ambient Humidity
10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Pollution Degree 2
Vibration
Resistance
IEC 61131-2 Compliant
5Hz≦f＜9Hz = Continuous: 1.75mm / Occasional: 3.5mm
9Hz≦f≦150Hz = Continuous: 0.5g / Occasional: 1.0g
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
140.8 x 104.8 x 44.8 184.1 x 144.1 x 47
Panel Cutout
(W) x (H) mm
118.8 x 92.8 172.4 x 132.4
Weight Approx. 315g Approx. 310g Approx. 760g
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum driving current
is supplied to HMI. The life of LED backlight shown here is an estimated value under 25
o
C normal temperature and
humidity conditions.
2) Users please use isolated power supply except DOP-A80THTD1, DOP-AE80THTD and DOP-A(E)10THTD1 these
models.
3) Users can download the Screen Editor V1.05, the program editor of Delta HMI product and the user manual via the
following link: 1http://www.delta.com.tw/industrialautomation/.
4) The content of this quick start may be revised without prior notice. Please consult our distributors or download the
most updated version at 2http://www.delta.com.tw/industrialautomation/.
