English-13
MODEL A(E)57CSTD
A80THTD1
AE80THTD
A(E)10THTD1
Vibration
Resistance
IEC 61131-2 Compliant
5Hz f≦ ＜9Hz = Continuous: 1.75mm / Occasional: 3.5mm
9Hz f 150Hz = Continuous: 0.5g / Occasional: 1.0g≦≦
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
184.1 x 144.1 x 47 243.1 x 178.1 x 52.4 297.1 x 222.1 x 51.1
Panel Cutout
(W) x (H) mm
172.4 x 132.4 231.4 x 166.4 285.2 x 210.2
Weight Approx. 760g Approx. 1140g Approx. 1735g
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum driving current
is supplied to HMI. The life of LED backlight shown here is an estimated value under 25
o
C normal temperature and
humidity conditions.
2) Users please use isolated power supply except DOP-A80THTD1, DOP-AE80THTD and DOP-A(E)10THTD1 these
models.
3) Users can download the Screen Editor V1.05, the program editor of Delta HMI product and the user manual via the
following link: 3http://www.delta.com.tw/industrialautomation/.
4) The content of this quick start may be revised without prior notice. Please consult our distributors or download the
most updated version at 4http://www.delta.com.tw/industrialautomation/.
