*1: AD indicator: If the indicator blinks, it means that AD/DA conversion is being executed.
*2: ALARM indicator: If the indicator blinks, it means that the AD/DA conversion value exceeds the range which
can be used.
*3: Installing a battery: Users have to replace the battery in the PLC in three minutes. Please refer to section 3.2
for more information.
Electrical Specifications
Electrical Specifications
Model
Item
DVP10SX11R/T DVP08SM11N DVP08SN11R/T DVP08SP11R/T DVP16SP11R/T
Power supply voltage
CPU: 24VDC (-15% ~ 20%) (with DC input reverse polarity protection),
Expansion Unit: supplied by the CPU
Fuse 2A / 250VAC -
Power Consumption 5W 1W 1.5W 1.5W 2W
Insulation Resistance > 5 MΩ at 500 VDC (Between all inputs / outputs and earth)
Noise Immunity
ESD: 8KV Air Discharge
EFT: Power Line: 2KV, Digital I/O: 1KV, Analog & Communication I/O: 250V
Damped-Oscillatory Wave: Power Line: 1KV, Digital I/O: 1KV
RS: 26MHz~1GHz, 10V/m
Grounding
The diameter of grounding wire cannot be smaller than the wire diameter of terminals L and N
(All DVP units should be grounded directly to the ground pole).
Environment
Operation: 0°C ~ 55°C (temperature), 5 ~ 95% (humidity), Pollution degree 2;
Storage: -25°C ~ 70°C (temperature), 5 ~ 95% (humidity); D/A output operation: 0°C ~ 50°C
(temperature)
Vibration / Shock
Resistance
Standard: IEC61131-2, IEC 68-2-6 (TEST Fc)/IEC61131-2 & IEC 68-2-27 (TEST Ea)
Weight (approx.) (g) 138 / 133 64 88 / 68 90 / 70 96 / 76
Approvals
Electrical Specification of Input Point Electrical Specification of Output Point
Input Type DC (SINK or SOURCE) Output Type Relay-R Transistor-T
Input Current 24VDC 5mA
Current
Specification
1.5A/1 point
(5A/COM)
0.3A/1 point @ 40°C; When the output of Y0 and
Y1 is high-speed pulse, Y0 and Y1 = 30mA
Active Level
Off → On,
X0,X1: above 18.5VDC
X2,X3: above 16.5VDC
Voltage
Specification
Below
250VAC,
30VDC
30VDC
On→Off,
X0~X3 below 8VDC
Maximum
Loading
75VA
(Inductive)
9W/1 point
When the output of Y0 and Y1
is high-speed pulse, Y0 and
Y1 = 0.9W (Y0 = 32kHz, Y1 =
10kHz)
Responding
Time
About 10ms (An
adjustment range of 0 ~ 20
ms could be selected
through D1020 and D1021)
90 W
(Resistive)
Responding
Time
About 10
ms
Off→On 20us
On→Off 30us
Y0 and Y1 are specified points
for high-speed pulse
Model Name & I/O Configuration
Model Power
Input Output
Point Type Point Type
DI AI DI AI DO AO DO AO
DVP10SX11R
24VDC
+20%
-15%
4 2
DC24V/5mA
Sink or
Source
-20 ~ 20mA
range(-1,000 ~ +1,000)
-10 ~ +10V
range(-2,000 ~ +2,000)
2 2 Relay
-20 ~ 20mA
(range:-2,000 ~ +2,000)
-10 ~ +10V
(range:-2,000 ~ +2,000)
DVP10SX11T 4 2 2 2 Resistor
Installation & Wiring
3.1 PLC Mounting Arrangements and Wiring Notes
