Delta DVP04AD-E2 - Control Register

- 3 -
Analog / Digital module (04A/D)
Max. rated power
consumption
1W, supplied by external power source
Connector European standard removable terminal block (Pin pitch: 5mm)
Operation/storage
temperature
Operation: 0°C~55°C (temp.), 5~95% (humidity), Pollution degree2
Storage: -25°C~70°C (temp.), 5~95% (humidity)
Vibration/shock
immunity
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Series connection to
DVP-PLC MPU
The modules are numbered from 0 to 7 automatically by their
distance from MPU. Max. 8 modules are allowed to connect to MPU
and will not occupy any digital I/O points.
 Functions Specifications
Analog / Digital module Voltage input Current input
Analog input channel 4 channels / each module
Range of analog input ±10V ±5V ±20mA 0 ~ 20mA 4 ~ 20mA
Range of digital
conversion
±32,000 ±32,000 ±32,000 0 ~ 32,000 0 ~ 32,000
Max./Min. range of
digital data
±32,384 ±32,384 ±32,384 -384~+32,384 -384~+32,384
Hardware Resolution 14 bits 14 bits 14 bits 13 bits 13 bits
Input impedance
≧1MΩ
250Ω
Range of absolute input ±15V ±32mA
Overall accuracy
0.5% when in full scale (25°C, 77°F)
1% when in full scale within the range of 0 ~ 55°C (32 ~ 131°F)
Response time
400μs / each channel
Digital data format 2’s complement of 16 bits
Average function
Supported. Available for setting up sampling range in CR#8 ~
CR#11. Range: K1 ~ K100.
Self-diagnosis Upper and lower bound detection in all channels
Isolation method
Optical coupler isolation between digital circuits and analog circuits.
No isolation among analog channels.
500VDC between digital circuits and Ground
500VDC between analog circuits and Ground
500VDC between analog circuits and digital circuits
500VDC between 24VDC and Ground
 Control Register
CR# Attrib. Register name Explanation
#0 O R Model name
Set up by the system:
DVP04AD-E2 model code = H’0080
#1 O R Firmware version Display the current firmware version in hex.
#2 O R/W CH1 input mode setting
Input mode: Default = H’0000.
Take CH1 for example:
Mode 0 (H’0000): Voltage input (±10V)
Mode 1 (H’0001): Voltage input (±5V)
Mode 2 (H’0002): Voltage input (0 ~ +10V)
Mode 3 (H’0003): Voltage input (0 ~ +5V)
Mode 4 (H’0004): Current input (±20mA)
Mode 5 (H’0005): Current input (0 ~ +20mA)
Mode 6 (H’0006): Current input (+4~ +20mA)
Mode -1 (H’FFFF): Channel 1 unavailable
#3 O R/W CH2 input mode setting
#4 O R/W CH3 input mode setting
#5 O R/W CH4 input mode setting
