Chapter 4 Communication Setting
LD-E Operation Manual
4-3
0x0F: Window size 15
1014H (R/W) (03H,06H)
Output delay
mode setting
0x01: Normal output mode (Default)
0x02: Off-delay
0x03: On-delay
0x04: One-shot
1015H (R/W) (03H,06H) Output delay time
Range:
0x0000~0x03E8: (0~1000ms)
0x05 (Default value)
1016H (R/W) (03H,06H)
Action output
Normally open/
Normally closed
0x01: Normally closed (Default value)
0x02: Normally open
1017H (R/W) (03H,06H)
External input
function
0x01: No function (Default value)
0x02: Zero function
0x03: Turn off the laser
0x04: Trigger function
1018H (R/W) (03H,06H)
Hysteresis setting
(Hys)
LD-500E、LD-500E、LD-220E、LD-100E:
unit: 0.1mm
1019H (R/W) (03H,06H)
Automatic/
manual
adjustment of
exposure level
0x01: Automatic adjustment
0x02: Manual adjustment
101AH (R/W) (03H,06H)
Manual exposure
setting hierarchy
Exposure level setting in manual mode
0x01~0x64 (1~100)
101BH (R/W) (03H,06H)
Detection output
setting
0x00: General detection mode
0x01: 1 point teaching (window comparison
mode)
0x02: 2 point teaching (window comparison
mode)
0x03: 3 point teaching (window comparison
mode)
101CH ~ 101DH
(R)
(03H)
Read firmware
version
Read firmware version
101EH (R) (03H) DO status read
0x00 : Not output
0x01: Start output
101FH (R) (03H) DI status read
0x00 : Not input
0x01: Start input
10C7H (R) (06H)
Restore factory
settings
0x01: Restore factory settings
