Delta VFD037B23A

Appendix B Accessories_VFD-B Series
B-32 Revision 10/2005, BE13, SW V4.08
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
5.5
7.5
18 27 1.5 2.5
7.5
10
18 27 1.5 2.5
11
15
25 37.5 1.2 2
15
20
35 52.5 0.8 1.2
18.5
25
45 67.5 0.7 1.2
22
30
45 67.5 0.7 1.2
30
40
80 120 0.4 0.7
37
50
80 120 0.4 0.7
45
60
100 150 0.3 0.45
55
75
130 195 0.2 0.3
75
100
160 240 0.15 0.23
575V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
0.75
1
2 3 20 32
1.5
2
4 6 9 12
2.2
3
4 6 9 12
3.7
5
8 12 5 7.5
5.5
7.5
8 12 3 5
7.5
10
12 18 2.5 4.2
11
15
18 27 1.5 2.5
15
20
25 37.5 1.2 1.8
18.5
25
25 37.5 1.2 1.8
22
30
35 52.5 0.8 1.2
30
40
45 67.5 0.7 1.2
37
50
55 82.5 0.5 0.85
45
60
80 120 0.4 0.7
55
75
80 120 0.4 0.7
75
100
100 150 0.3 0.45
