Delta VFD055CP43B-21

Chapter 11 Summary of Parameter SettingsCP2000
11-10
Pr. Parameter Name Settings Range Default
01-30
Skip frequency 2 (upper limit)
0.00–599.00 Hz 0.00
01-31
Skip frequency 2 (lower limit)
0.00–599.00 Hz 0.00
01-32
Skip frequency 3 (upper limit)
0.00–599.00 Hz 0.00
01-33
Skip frequency 3 (lower limit)
0.00–599.00 Hz 0.00
01-34 Zero-speed mode
0: Waiting for output
1: Zero-speed operation
2: Minimum frequency (Refer to Pr.01-07, 01-41)
0
01-35 Output frequency of motor 2 0.00–599.00 Hz
60.00 /
50.00
01-36 Output voltage of motor 2
230V: 0.0–255.0 V
460V: 0.0–510.0 V
575V: 0.0–637.0 V
690V: 0.0–765.0 V
200.0
400.0
575.0
660.0
01-37 Mid-point frequency 1 of motor 2 0.00–599.00 Hz 3.00

01-38 Mid-point voltage 1 of motor 2
230V: 0.0–240.0 V
460V: 0.0–480.0 V
575V: 0.0–637.0 V
690V: 0.0–720.0 V
Motor drive with 690V, 185 kW and above: 10.0
11.0
22.0
0.0
0.0
01-39 Mid-point frequency 2 of motor 2 0.00–599.00 Hz 1.50

01-40 Mid-point voltage 2 of motor 2
230V: 0.0–240.0 V
460V: 0.0–480.0 V
575V: 0.0–637.0 V
690V: 0.0–720.0 V
Motor drive with 690V, 185 kW and above: 2.0
5.0
10.0
0.0
0.0
01-41 Min. output frequency of motor 2 0.00–599.00 Hz 0.50

01-42 Min. output voltage of motor 2
230V: 0.0–240.0 V
460V: 0.0–480.0 V
575V: 0.0–637.0 V
690V: 0.0–720.0 V
1.0
2.0
0.0
0.0
01-43 V/F curve selection
0: V/F curve determined by Pr.01-00–01-08
1: 1.5
th
V/F curve
2: 2
nd
V/F curve
3: 60 Hz, voltage saturation in 50 Hz
4: 72 Hz, voltage saturation in 60 Hz
5: 50 Hz, decrease gradually with cube
6: 50 Hz, decrease gradually with square
7: 60 Hz, decrease gradually with cube
8: 60 Hz, decrease gradually with square
9: 50 Hz, medium starting torque
10: 50 Hz, high starting torque
11: 60 Hz, medium starting torque
12: 60 Hz, high starting torque
13: 90 Hz, voltage saturation in 60 Hz
14: 120 Hz, voltage saturation in 60 Hz
15: 180 Hz, voltage saturation in 60 Hz
0
