Chapter 12 Description of Parameter SettingsCP2000
12.1-00-5
If Pr.00-04 is set to 17 or 20, it displays in hexadecimal “0001h” with LED u page is ON in the
keypad.
The setting value 17 is ON / OFF status of digital output according to Pr.02-18 setting, and the
setting value 20 is the corresponding CPU pin ON / OFF status of the digital output.
You can set 17 to monitor the digital output status, and then set 20 to check if the circuit is
normal.
Explanation 4
Setting value 25: when displayed value reaches 100.00%, the drive shows “oL” as an overload
warning.
Explanation 5
Setting value 38:
bit 0: The drive is running forward.
bit 1: The drive is running backward.
bit 2: The drive is ready.
bit 3: Errors occurred on the drive.
bit 4: The drive is running.
bit 5: Warnings occurred on the drive.
Coefficient Gain in Actual Output Frequency
Default: 1.00
Settings 0.00–160.00
Sets the user-defined unit coefficient gain. Set Pr.00-04= 31 to display the calculation result on
the screen (calculation = output frequency * Pr.00-05).
Software Version
Default: Read only
Settings Read only
Parameter Protection Password Input
Default: 0
Settings 0–65535
Display 0–4 (the number of password attempts)
This parameter allows you to enter your password (which is set in Pr.00-08) to unlock the
parameter protection and to make changes to the parameter.
To avoid problems in the future, be sure to write down the password after you set this parameter.
Pr.00-07 and Pr.00-08 are used to prevent personnel from setting other parameters by accident.
If you forget the password, clear the password setting by entering 9999 and press the ENTER
key, then enter 9999 again and press ENTER within 10 seconds. After decoding, all the settings
return to default.
When setting is under password protection, all the parameters read 0, except Pr.00-08.
