Chapter 12 Description of Parameter SettingsCP2000
12.1-03-21
5: Three-point curve of AVI 1& AVI2
6: Three-point curve of ACI & AVI2
7: Three-point curve of AVI1 & ACI & AVI2
 Sets the calculation method for analog input.
 When Pr.03-50=0, all analog input signal is calculated by bias and gain.
 When Pr.03-50=1, AVI1 calculates by frequency and voltage / current (Pr.03-51–Pr.03-56), other
analog input signal calculates by bias and gain.
 When Pr.03-50=2, ACI calculates by frequency and voltage / current (Pr.03-57–Pr.03-62), other
analog input signal calculates by bias and gain.
 When Pr.03-50=3, AVI1 and ACI calculate by frequency and voltage / current (Pr.03-51–Pr.03-62),
other analog input signal calculate by bias and gain.
 When Pr.03-50=4, AVI2 calculates by frequency and voltage (Pr.03-63–Pr.03-68), other analog
input signal calculates by bias and gain.
 When Pr.03-50=5, AVI1 and AVI2 calculate by frequency and voltage / current (Pr.03-51–Pr.03-56
and Pr.03-63–Pr.03-68), other analog input signal calculate by bias and gain.
 When Pr.03-50=6, ACI and AVI2 calculate by frequency and voltage / current (Pr.03-57–Pr.03-68),
other analog input signal calculates by bias and gain.
 When Pr.03-50=7, all analog input signal calculate by frequency and voltage / current (Pr.03-51–
Pr.03-68).

AVI1 Lowest Point
Default:
0.00 / 0.00 / 4.00
Settings Pr.03-28=0, 0.00–10.00 V
Pr.03-28=1, 0.00–20.00 mA
Pr.03-28=2, 0.00–20.00 mA

AVI1 Proportional Lowest Point
Default: 0.00
Settings -100.00–100.00%

AVI1 Mid-Point
Default:
5.00 / 10.00 / 12.00
Settings Pr.03-28=0, 0.00–10.00 V
Pr.03-28=1, 0.00–20.00 mA
Pr.03-28=2, 0.00–20.00 mA

AVI1 Proportional Mid-Point
Default: 50.00
Settings -100.00–100.00%
