Delta VFD185B43A User Manual

Chapter 5 Parameters_VFD-B Series
5-60
Revision 10/2005, BE13, SW V4.08
Settings Function Description
16 Auxiliary Motor No.1 output disable
17 Auxiliary Motor No.2 output disable
18 Auxiliary Motor No.3 output disable
Parameter value 16 to 18 program Multi-Function Input Terminal
to disable the corresponding auxiliary motor via the AC motor
drive Multi-function Output Terminals Pr.03-00 to 3-03 (Relay
and MO1 to MO3) when set to 16-18.
19 Emergency Stop (N.O.)
20 Emergency Stop (N.C.)
When set to 19 or 20, the Multi-Function Input Terminal can be
used to stop the AC motor drive in case of malfunction in the
application. It will display “EF1”. Please “RESET” after the fault
has been cleared.
Refer to Pr.02-02 for Stop Method.
21
Master Frequency Selection
AVI/ACI
ON: ACI
OFF: AVI
Pr.02-00 and Pr.02-13 are disabled if this parameter value 21 is
set. See the explanation below the table.
22
Master Frequency Selection
AVI/AUI
ON: AUI
OFF: AVI
Pr.02-00 and Pr.02-13 are disabled if this parameter value 22 is
set. See the explanation below the table.
23
Operation Command Selection
(keypad PU01/external terminals)
ON: Operation command via Ext. Terminals
OFF: Operation command via Keypad PU01
Pr.02-01 and Pr.02-14 are disabled if this parameter value 23 is
set. See the explanation below the table.
24 Auto accel/decel mode disable
ON: Linear accel/decel (Auto accel/decel mode set by Pr.01-15
disabled)
OFF: Auto accel/decel mode
25 Forced Stop (N.C.)
26 Forced Stop (N.O.)
These two parameters have the same function as the “STOP”
command with stop method acc. to Pr.02-02. No error message
is displayed. When parameter value 25 or 26 is enabled, a new
RUN command is needed.
27 Parameter lock enable (N.O.)
When this setting is enabled, all parameters will be locked and
write parameters is disabled.
28 PID function disabled When input ON with this setting, PID function will be disabled.
29 Jog FWD/REV command
ON: REV
OFF: FWD
This command will be effective only when external terminal JOG
is active.
