Chapter 7 Optional AccessoriesMS300

116

LED

Descriptions

CANopen–ERR

ERR LED:

LED

status

Condition/ State

OFF

No Error

Single

Flash

At least one packet of CANopen is in failure

Double

Flash

Node guarding failure or heartbeat message failure

Triple

Flash

Synchronization failure

Bus off
