Delta VFD2A7MS43ANSAA User Manual

Chapter 9 SpecificationsMS300
192
9-7-3 Derating Curve for Carrier Frequency
Normal load (Pr.00-16 = 0)
 Space Vector Modulation Mode (Pr.11-41 = 2)
Figure 9-7
The rated output current (%) of SVPWM in normal load for different carrier frequencies:
Carrier Freq.
(kHz)
Ambient Temp.
(Ta), 100% Load
2
3
4
5
6
7
8
9
10
11
12
13
14
15
50°C
100
96
86
77
69
62
56
51
46
42
38
35
32
29
40°C
100
100
100
90
82
74
68
62
56
52
48
44
40
37
35°C
100
100
100
96.5
88.5
80
74
67.5
61
57
53
48.5
44
41
Table 9-15
 Two-phase Modulation Mode (Pr.11-41 = 0)
Figure 9-8
The rated output current (%) of DPWM in normal load for different carrier frequencies:
Carrier Freq.
(kHz)
Ambient Temp.
(Ta), 100% Load
2
3
4
5
6
7
8
9
10
11
12
13
14
15
50°C
100
100
100
88
80
72
66
60
55
51
47
44
41
38
40°C
100
100
100
100
100
93
87
82
77
72
68
64
60
56
35°C
100
100
100
100
100
100
97.5
93
88
82.5
78.5
74
69.5
65
Table 9-16
