Delta VFD2A7MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
214
Pr.
Explanation
Settings
Default

01-17
Deceleration Time 3
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-18
Acceleration Time 4
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-19
Deceleration Time 4
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-20
JOG Acceleration Time
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-21
JOG Deceleration Time
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-22
JOG Frequency
0.00–599.00 Hz
6.00

01-23
Switch Frequency between
First and Fourth
Accel./Decel.
0.00–599.00 Hz
0.00

01-24
S-Curve for Acceleration
Begin Time 1
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20

01-25
S-Curve for Acceleration
Arrival Time 2
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20

01-26
S-Curve for Deceleration
Begin Time 1
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20

01-27
S-Curve for Deceleration
Arrival Time 2
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20
01-28
Skip Frequency 1
(Upper Limit)
0.00–599.00 Hz
0.00
01-29
Skip Frequency 1
(Lower Limit)
0.00–599.00 Hz
0.00
01-30
Skip Frequency 2
(Upper Limit)
0.00–599.00 Hz
0.00
01-31
Skip Frequency 2
(Lower Limit)
0.00–599.00 Hz
0.00
01-32
Skip Frequency 3
(Upper Limit)
0.00–599.00 Hz
0.00
01-33
Skip Frequency 3
(Lower Limit)
0.00–599.00 Hz
0.00
01-34
Zero-Speed Mode
0: Output waiting
1: Zero-speed operation
2: Fmin (refer to Pr.01-07 and Pr.01-41)
0
01-35
Rated / Base Frequency of
Motor 2
0.00–599.00 Hz
60.00 /
50.00
