Delta VFD2A7MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
221
Pr.
Explanation
Settings
Default
30: Output when frequency < Pr.02-34
31: Y-connection for the motor coil
32: -connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed including STOP (actual output frequency)
35: Error output selection 1 (Pr.06-23)
36: Error output selection 2 (Pr.06-24)
37: Error output selection 3 (Pr.06-25)
38: Error output selection 4 (Pr.06-26)
40: Speed reached (including STOP)
42: Crane function
43: Motor speed detection
44: Low current output (use with Pr.06-71–06-73)
45: UVW output electromagnetic valve switch
46: Master dEb output
50: Output control for CANopen
51: Analog output control for RS-485 interface
52: Output control for communication cards
53: Fire mode indication
66: SO output logic A
67: Analog input level reached
68: SO output logic B
73: Over-torque 3
74: Over-torque 4
75: Forward RUN status
76: Reverse RUN status

02-18
Multi-Function Output
Direction
0000h–FFFFh (0: N.O.; 1: N.C.)
0000h

02-19
Terminal Counting Value
Reached (Returns To 0)
0–65500
0

02-20
Preliminary Counting Value
Reached
(does not return to 0)
0–65500
0

02-21
Digital Output Gain (DFM)
1–55
1

02-22
Desired Frequency
Reached 1
0.00–599.00 Hz
60.00 /
50.00

02-23
The Width of the Desired
Frequency Reached 1
0.00–599.00 Hz
2.00

02-24
Desired Frequency
Reached 2
0.00–599.00 Hz
60.00 /
50.00
