Delta VFD2A7MS43ANSAA User Manual

Chapter 12 Descriptions of Parameter SettingsMS300
350
05-33
Induction Motor (IM) or Permanent Magnet Synchronous AC Motor
Selection
Default: 0
Settings
0: IM (Induction motor)
1: SPM (Surface permanent magnet synchronous AC motor)
2: IPM (Interior permanent magnet synchronous AC motor)
05-34
Full-load Current for a Permanent Magnet Synchronous AC Motor
Default: Depending on the
model power
Settings
0–120% of the drive’s rated current
05-35
Rated Power for a Permanent Magnet Synchronous AC Motor
Default: Depending on the
motor power
Settings
0.00–655.35 kW
 Sets the rated power for the permanent magnet synchronous AC motor. The default is the drive’s
power value.
05-36
Rated Speed for a Permanent Magnet Synchronous AC Motor
Default: 2000
Settings
0–65535 rpm
05-37
Number of Poles for a Permanent Magnet Synchronous AC Motor
Default: 10
Settings
0–65535
05-39
Stator Resistance for a Permanent Magnet Synchronous AC Motor
Default: 0.000
Settings
0.000–65.535 
05-40
Permanent Magnet Synchronous AC Motor Ld
Default: 0.00
Settings
0.00–655.35 mH
05-41
Permanent Magnet Synchronous AC Motor Lq
Default: 0.00
Settings
0.00–655.35 mH
05-43
Ke parameter of a Permanent Magnet Synchronous AC Motor
Default: 0
Settings
0–65535 V/krpm
05-51
Motor Code
Default: 0
Settings
0–65535
 When using Delta MSI Motor, set Pr.05-51 according to the corresponding setting value in the
table below to complete motor auto-tuning.
