Chapter 16 PLC Function ApplicationsMS300
658
16-1 PLC Summary
16-1-1 Introduction
The commands provided by the MS300’s built-in PLC functions, including the ladder diagram editing
tool WPLSoft, as well as the use of basic commands and application commands, follow the operating
methods of Delta’s PLC DVP series.
16-1-2 WPLSoft ladder diagram editing tool
WPLSoft is Delta's software program for the DVP and MS300 programmable controllers in Windows
operating system environment. In addition to general PLC program design and general Windows
editing functions (such as cut, paste, copy, and multiple windows), WPLSoft also provides many
features such as Chinese/English annotation editing, registry editing, settings, file reading, saving,
and contact graphic monitoring and settings.
Table 16-1 lists the basic requirements for installing the WPLSoft editing software:
Item
System requirements
Operating System
Windows 95 / 98 / 2000 / NT / ME / XP / 7 /10
CPU
At least Pentium 90
Memory
At least 16 MB (we recommend at least 32 MB)
Hard Drive
Hard drive capacity: at least 100 MB of free space
One optical drive (to install this software)
Display
Resolution: 640×480, at least 16 colors; it is recommended that the screen
area be set at 800×600 pixels.
Mouse
Ordinary mouse or Windows-compatible pointing device
Printer
Printer with Windows driver software
RS-485 Port
Must have at least an RS-485 port to link to the PLC
Table 16-1
