7.4 DigitalOutputBehaviorDefine
Group:do_i<0~(k‐1)>forkisthevalueof"capability_ndo"(capability_ndo>0)
kisdeterminedbythebelowcriterion:
Thefollowingappliesforcapability_extension_do_num>=0
*ifextension_connected=1,k=capability_ndo
*ifextension_connected=0,k=capability_ndo+capability_extension_do_num
Otherwise,
*k=capability_ndo
NAME VALUE SECURITY
(get/set)
DESCRIPTION
normalstate open,
grounded
1/1 Indicateopencircuitorclosedcircuit
(inactivestatu s)

7.5 Security
Group:security
NAME VALUE SECURITY
(get/set)
DESCRIPTION
privilege_do

view,operator,
admin
1/6 Indicatewhichprivilegesandabove
cancontroldigitaloutput
(capability_ndo>0)
privilege_camctrl

view,operator,
admin
1/6 Indicatewhichprivilegesandabove
cancontrolPTZ
(capability_ptze n a bl e d>0or
capability_eptz>0or
capability_fisheye>0)
user_i0_name string[64] 6/7 Usernameofroot
user_i<1~20>_name string[64] 6/7 Username
user_i0_pass password[64] 7/6 Rootpassword
user_i<1~20>_pass password[64] 7/6 Userpassword
user_i0_privilege view,
operator,
admin
6/7 Rootprivilege
user_i<1~20>_privilege

view,
operator,
admin
6/6 Userprivilege
