7.34 RegionofInterest
Group:roi_c<0~(n‐1)>fornchannelproductandmistheindexofvideostreamwhichsupportePTZ.
(capability_eptz>0)
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
s<0~(m‐1)>_home <W,H>
<product
dependent>
1/6 ROIleft‐topcornercoordinate.
*Iftheminimalwindowsizeis64x64,
thenthe"home"=(0~resolution_W‐64,
0~resolution_H‐64),whichtheresolution
isequaltothecapturedsizebydevicein
thisvideomode. 

*Ifthestreamdoesn’tsupportePTZ,the
permissionsofthisparametermustbe
setas1/7.
s<0~(m‐1)>_size <WxH>
<product
dependent>
1/6 ROIwidthandheight.Thewidthvalue
mustbemultiplesof16andtheheight
valuemustbemultiplesof8
*Iftheminimalwindowsizeis64x64,
thenthe"size"=(64~resolution_W,
64~resolution_H),whichtheresolutionis
equaltothecapturedsizebydevicein
thisvideomode. 

*Ifthestreamdoesn’tsupportePTZ,the
permissionsofthisparametermustbe
setas1/7.

7.35 ePTZSetting
Group:eptz_c<0~(n‐1)>fornchannelproduct.(capability_eptz>0)
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
